FKD-N Regular Pump

3-piston alternating volumetric pumps for use on cleaning units and industrial systems. It can be coupled to various types of motors, directly or with flexible joints. Pump body and cover in die-cast aluminum alloy. The side cover may be blind or incorporate oil sight glass. Rear cover with an oil drain outlet. Pistons driven by crank-connecting rod mechanism. Pump shaft in pressed high-strength steel. Oversized friction bearings. Connecting rods in die-cast special low-friction zinc-aluminium alloy. One-piece ceramic pistons. Pump head in pressed brass—double gasket sealing system. Intake and delivery valves have plugs for easier maintenance.

● Designed for high-pressure water systems
● New pump head structure design
● Ceramic plunger.

PREV：FKD-F10 Brass Acid Pickling Regular Pump NEXT：FKD-F01 Regular Pump

Product Roadmap

Product Data

● FKD-N.1450rpm N version Ø24mm

Model	FloW		Pressure		Power		Speed	Inlet	Outlet	Weight
Model	L/min	gpm	bar	psi	hp	kw	rpm	thread	thread	KG
FKD1535	15.4	4	350	5075	14	10.5	1450	G1/2"	G3/8"	11.2
FKD2035	20	5.3	350	5075	18.6	14	1450	G1/2"	G3/8"	11.2
FKD2615	26	6.8	150	2200	10	7.5	1450	G3/4"	G3/8"	11.2
FKD3015	30	7.9	150	2200	12	9	1450	G3/4"	G3/8"	11.2
FKD4015	40	10.5	150	2200	16	12	1450	G3/4"	G3/8"	11.2
